Product Details

DC Electromagnetic Brakes (KCH, KBD)

Description

Key Features:

• Wound Coil Options: Available with shunt or series wound coils for versatile applications.
• Fail-Safe Operation: Designed to ensure reliable braking, even during power failure.
• Epoxy-Encapsulated Coils: Class "F" insulated coils for enhanced durability and performance.
• Rigid Shoe Positioner: Ensures brake shoes remain properly aligned, preventing tilting or riding the drum when released.
• Manual Release: Easy manual release by turning the release nuts.
• Torque Adjustment: Adjust torque settings by compressing the torque spring to the desired marking.
• Limit Switch Attachments: Includes options for monitoring brake release and lining wear.
• KAKKU Rectifier Panels: Compatible with KAKKU standard brake rectifier panels for converting AC supply to DC for seamless operation.
• Standards Compliance: Conforms to IPSS, RUSSIAN, AISE, and NEMA standards.

Available Sizes (Drum Diameter):

• KBD: 100, 150, 160, 200, 250, 300, 315, 400, 500, 600, 700, 800 mm.
• KCH: 8, 10, 13, 16, 19, 23 inches.
